Fyrir hæð: 125cm - 145cm
Geometry
| Wheel Size | 20" | |
|---|---|---|
| Travel (mm front/mm rear) | 120/100 | |
| Reach | 320 | |
| Stack | 443 | |
| HTA | Head Tube Angle | 64.0 |
| OS | Fork Offset | 40 |
| ST | Seat Tube Length | 255 |
| STA | Effective Seat Tube Angle | 75.0 |
| RC | Rear Centre Length | 355 |
| BB | Bottom Bracket Rise/Drop | 10 |
| BBH | Bottom Bracket Height | 270 |
| HTT | Horizontal Top Tube | 439 |
| WB | Wheelbase | 640 |
| SOH | Standover | 500 |
| HT | Head Tube Length | 90 |
| Trail | 83 | |
| Recommended Seatpost Drop | 80 | |
| Maximum Post Insertion | 130 | |
| Stem Length | 35 | |
| Crank Length | 140 | |
| Tire Size | 2.35" - 2.6" |
